Guided Growth System
Whatever the etiology is, the plate is placed for gradual correction of the angled deformities of upper and lower extremities (on the ends of long bones) during the adolescence and puberty periods (from 18months old up to 17 years old).
Ankle valgus, elbow varus, knee valgus and varus, and oblique plan flexion deformity and recurvatum cases can be evaluated in this scope.
Ankle valgus, elbow varus, knee valgus and varus, and oblique plan flexion deformity and recurvatum cases can be evaluated in this scope.
Femoral Set
Tibial Set
Wide rotation Angle
Simple, minimum invasive technique.
Joint effect with wider angle to avoid compression makes the system superior over the rigid staples method.
Joint effect with wider angle to avoid compression makes the system superior over the rigid staples method.
Book Now
Self Cutting Screw Tip
Modified screw tip for improved cutting.
Screwdriver
Cannulated
Book Now
Drill
Cannulated
Insert the Guide Pin in PHYSIS and confirm position.
Then apply plate over the pin
Then apply plate over the pin
The pin jig will align with the center of the plate hole.
The pin is inserted through the guide jig.
The cannulated drill will be guided by the pin.
The screw and screwdriver will be guided by the pin.
Repeat for other screw.
Repeat for other screw.
The pins are then removed.
Final stage reached.
